Supervising Digital Colourist

Hybrid

Hybrid was my first opportunity to collaborate with John Leonetti, ASC, a great cinematographer and good friend! Looking at the images you’d never guess that half of this feature was shot in almost complete darkness, and with an early build of the Red One camera. John nailed the exposure, and gave us some great images to work with.

Hybrid by STALLION MEDIA © 2010

Hybrid was shot in the days before the MX upgrade to the Red One camera, a time when every DP was trying to get the most light onto the sensor. The lenses John picked for Hybrid were the Cooke S4s as well as the Angenieux Optimo zooms, both great lenses with very high optical qualities. The camera was rated at ISO 320.

Emergency Lighting

Most of Hybrid takes place in a five-story car park. In the first half of the movie we cut between the various levels, including the office, the mechanics’ workshop and the ramps connecting each level. For these setups John combined different types of lighting: “I mixed kelvins in the practical lighting intentionally to give color separation. We mixed 3200k, incandescent with 5600, daylight and fluorescents which were cool white, blue and green.”

In the second part of the movie, a car crash that takes out the building transformer, emergency lights are triggered, and hence we called this setup ’emergency mode’. John and I decided that as we descended through the levels, the picture would get darker. This required planning, for example knowing how dark we could go on level 2 so that we still had a picture by the time we reached level 5! “You always need somewhere to go,” John would often tell me if he felt we were going too dark.

This setup meant that we ended up grading ‘hero’ shots when John was available, establishing a look for key moments in the story, and then filling in the shots around them when John had left for the day. Using this approach, we knew how dark we should be in each section before committing to grading the entire scene. You always want to use the time with the DP wisely, which is why this technique is quite common with DPs who have a busy schedule.

Debayered Image

Industrial Look

John is one of those DPs who really gets stuck into a project, colouring his own stills and laying them out to a Pink Floyd soundtrack! The stills were pulls from the original R3D files and coloured onset. He went further than most DPs in that he gave the stills a real punchy, saturated look. After talking about the movie, we definitely felt that we wanted to go for a strong ‘industrial’, gritty look, with rich cyans and blues creeping into the blacks, but not at the expense of the actors’ skin tones. We also wanted to bring out the ‘distressed’ look in the walls, the furniture and the cement floors.

Colour Curves

A strong look doesn’t have to mean an overpowering look devoid of detail; I like to retain the subtleties from the original ‘negative’, and for this type of job I opted to use curves to establish a new ‘base’ instead of using the joyballs. Curves are a very powerful tool but can also be tricky, because unlike the joyballs that are compensating all three primaries at the same time (add red and you take away green/blue at the same time), curves are additive unless you manually compensate. However, this also makes them ideal for making sweeping changes to an image. For example, take the Blue → Blue curve, crash down the black point and you end up with golden blacks, just like that!

Emergency Mode: Level 3

In the case of Hybrid, I played mostly with the Red → Red channel, bringing down the black point and then balancing that with the Green → Green channel to push my blacks and mids more towards blue. This is where it pays to know your colour wheel and your additive vs. subtractive way of colouring.

Now with a strongly biased base, anything you build on top will inherit those characteristics. This is when I will switch to the joyballs and master controls and add density and contrast, as well as push the mid tones to a warmer place. This teases apart the picture, giving you that colour separation that keeps the image interesting and ‘real’. I used this approach on most of the movie, except for the darkest scenes where I was trying to conserve as much of the picture as possible!

The Darkest moment in the movie

Dealing with Black

When the majority of your frame is made up of black, there is a tendency to really pull up the gain in an image to bring out anything that constitutes a picture. There are two problems with this: firstly, by pulling the highlights away from the blacks, you are exacerbating the noise level in the blacks, and that’s not a good thing. Secondly, if you push the gain hard enough your skin tones will start to ‘posterize’. Both of these are not good scenarios. What’s else can you do then?

The approach I use is a tiered one. I use the gamma to bring up whatever is visible in the picture up to a comfortable point, ie. before the noise becomes excessive. It’s important to set your pivot points so that the gamma has a minimal effect on your blacks, otherwise you’ll be lifting the noise! Then I’ll use a luminance map to select the brightest areas, and use the gain to pull out any remaining highlights.

It’s important to remember that the goal with these kinds of shots is not to create a perfectly distributed bell-shaped histogram, with lots of body and good highlights. We are merely trying to get a pleasant picture, and as long as the eye catches those highlights and a little bit of mid tone, you should be fine.

You can find more stills of Hybrid here.
